Glovebox gas purification

Any questions?

Phone +49 7246 7001 70

E-Mail gs@gs-glovebox.com

X-Line Purifier

Specifications

  • High quality manufacturing ISO 9001:2008
  • Fully automated 1 filter gas purifier for the highly efficient removal of O2 and H2O
  • Temperature control for the filter column
  • Achievable values for O2 and H2O < 1 ppm
  • For gloveboxes up to 2.6 m³
  • Regeneration: Inert gas with max 5% H2
  • Siemens PLC with 7“ color touch screen
  • GS ECO-Safety Mode < 100 W for standard system
  • Recording of values for O2, H2O and pressure for 5 days
  • Intuitive GS software
  • Automated pressure control of the glovebox (without vacuum pump)
  • Positive and negative pressure adjustable (without vacuum pump)
  • Fully automatied purification and regeneration
  • Circulation blower up to 52 m³/h
  • Circulation blower is vibration-cushioned, nearly noiseless
  • All purification systems work without any additional water-cooling!

E-Line Purifier

Additional specifications compared to X-Line

  • For gloveboxes up to 5.2 m³
  • Recording of O2, H2O and pressure for 60 days
  • Reading of the recorded data via USB interface
  • Alarms for O2 and H2O
  • Circulation blower up to 96 m³/h
  • Fully automated purging

M-Line Purifier

Additional specifications compared to E-Line

  • Fully automated 2 filter gas purifier for the highly efficient removal of O2 and H2O
  • Continuous gas purification even during regeneration phases

RG-Line Purifier

Additional specifications compared to M-Line

  • Fully automated multiple filter column gas purifier for the highly efficient removal of O2 and H2O
  • For gloveboxes up to 16.0 m³
  • Siemens PLC with 12“ color touch screen
  • Simultaneously working system with two blowers
  • Automated bypass-function for filters and sensors
  • Fast purging mode
  • Ventilation of the glovebox with atmospheric air possible
  • Pressure difference control for the HEPA filters

Optional

  • E- / M-Line gas purifier are upgradable with all listed features
  • Solvent vapor removal also regenerative
